A solid state oxygen sensor, based on fluorescence quenching. The sensing layer incorporates special dyes, which fluorescent when exposed to green light. The amplitude as well as the lifetime of the fluorescence light corresponds to the amount of oxygen.
Although our GREENFLASH O2 sensor is a digital sensor, is can also output an analog signal thanks to our patent pending smart interface technology. This allows using the sensor in already existing life support system, originally designed for galvanic O2 sensors.
Our GREENFLASH O2 Sensor has a lifetime of more than 5 years. In contrast, traditional galvanic sensors need to be replaced in 12 month intervals.
Standard Range: 10..100% O2
Extended Range: 0.1 .. 2 bar pO2
Response time t63: <2s
Accuracy: compliant to ISO 80601-2-55
RoHS compliant
Gas connection: M16x1mm thread
Diameter: 29mm
Height 28mm
Battery: CR2477
Housing Material: Polycarbonate and ABS
| SKU | GF-OXY100 |
|---|
we try to hold stock of all products, but if showing out of stock there may be a few days wait while new stock arrives.
